RXF 40

Water pressurisation machine

Enginered and made in Switzerland

Device designed for leak testing watches and other components by immersing them in pressurized water.
It can be pressurized up to 500 bar (~5’000 meters under water) for a configurable time.

Machine functions

  • Pressure up to 40 bar (~400 meters depth)
  • Stainless steel tank and water collection tray
  • Loading on trays
  • Electrical connection only
  • Touch-screen
  • Standard :
    • Water circuit fed from a tank using a pump
  • Alternative :
    • Water circuit that is fed directly from the mains water supply

Software fonctions

  • Intuitive menus in 5 languages
  • Many adjustable parameters
  • Simple programming of cycle times, step times and transition times
  • Up to 18 storable programs
  • History of last 10 cycles and faults stored in memory
  • Automatic tank filling and emptying function

Technical specifications

Supply voltage :
Power :
Working pressure :
Capacity :
Tank internal Ø :
Tank internal height :
Weight :
Dimensions closed device (l/d/h) :
Dimensions open device (l/d/h) :

110-230 V~ / 50-60 Hz
350 W
0 to 40 bar
Up to 12 watches
160 mm
100 mm
30 Kg
380 x 445 x 345 mm
510 x 445 x 525 mm

download the technical sheet
